Z Series Barcode Scanner
Z2S Bluetooth 2D QR Barcode Scanner
Z3S Bluetooth 1D CCD Barcode Scanner
Z5S Wi-Fi Wireless 2D QR Barcode Scanner
Z7S 4G Wireless 2D QR Barcode Scanner
Fetures
The Z2S is a portable barcode scanner designed for mobile work scenarios, combining compact size with powerful features to significantly improve data collection efficiency in logistics, retail, healthcare and other industries.
The Z2S scanner is mini-sized and fits in your pocket, enabling fast and convenient barcode reading on the go，Ergonomic design prevents fatigue during extended use.
It reads 1D barcodes from paper, phone screens, and computer displays—even damaged or blurry codes.Advanced decoding algorithm accurately reads blurry/damaged barcode.
Connects to smartphones, tablets, and PCs via Bluetooth or USB for seamless integration.
Stores data offline and syncs automatically when reconnected—ideal for areas with poor connectivity
Switch operating modes instantly by scanning a predefined barcode for maximum flexibility.
The rechargeable lithium battery offers 8+ hours of continuous use and is replaceable for extended lifespans.
Optimized for logistics, warehousing, asset tracking, healthcare, libraries, and retail to streamline operations.
Detailed Images
l Z2S Wireless 2D Barcode Scanner with Display
1 | Scanning Performance | |
1.1.2 | Resolution: | 640×480 |
1.1.3 | Illumination: | White LED (6500K) |
1.1.4 | Aiming: | Red LED (625nm) |
1.1.5 | Minimum Reading Precision: | 1D≥5mil Code39 2D≥7mil QR Code |
1.1.6 | Scanning Angle: | Rotation: 360°, Pitch: ±60°, Skew: ±60° |
1.1.7 | Field of View (FOV): | Horizontal: 42°, Vertical: 31° |
1.1.8 | Supported Symbologies: | 1D UPC-A/UPC-E、EAN13/EAN8/ISBN/ISSN、Code128/GS-128、Code39、Code93、Code32、Code11、Codabar、MSI PLSEEY、ITF25、STD25、Matrix25、IND25、HK25、Pharma code、Telepen、Trioptic code、Brazilian bank code、Postal Code 、GS1 Databar、GS1 Compsite code 2D QR Code/Mirco QR、Data Martrix、PDF417/Mirco pdf417、Aztec、Maxicode、Hanxin |
1.1.9 | Depth of Field (DOF): | Code128 5mil 6bit 4-10cm QR Code 20mil 16bit 2.5-25cm PDF417 6.8mil 6bit 3.5-22cm EAN13 13mil 13bit 4.5-27cm DataMartix 10mil 20bit 2.5-9.5cm |
1.2 | Print Contrast Ratio | ≥25% |
1.2.1 | Scanning Modes: | Manual trigger, Continuous scan, Auto-sensing |
2 | Wireless Parameters | |
2.1 | Transmission Methods | 2.4G Wireless + Bluetooth (supports Bluetooth 2.0, 3.0, 4.0, 4.2) + Wired USB |
2.2 | 2.4G: | Up to 65 meters (line of sight) |
Bluetooth: | Up to 20 meters (line of sight) | |
2.3 | Battery Capacity: | 1200mAh |
2.4 | Charging Time: | 3-4小时 |
2.5 | Standby Mode: | Enters standby after 3 minutes of inactivity |
2.6 | Charging Input: | 5V 2A |
2.7 | TFT Display: | Displays transmission mode, connection status, battery level, scan data, and status notifications |
3 | Electrical Parameters | |
3.1 | Operating Voltage: | DC 5V±5％ |
3.2 | Operating Current: | 215mA |
3.3 | Standby Current: | 0.6μA |
4 | Physical Characteristics | |
Dimensions (L × W × H): | 130*45*25（mm） | |
4.2 | Weight: | ≈72g |
4.3 | Cable Length: | 1.2m |
4.4 | Interface: | USB |
4.4 | Color: | White |
4.5 | Material:： | ABS |
4.6 | Notification Methods: | Buzzer, LED indicator, Vibration, TFT screen |
5 | Environmental Specifications | |
5.1 | Operating Temperature: | -10°C-50°C |
5.2 | Storage Temperature: | -20°C-70°C |
5.3 | Humidity: | 5%-95%（non-condensing） |
5.4 | Ambient Light Immunity: | 0~100000 LUX |
6 | Compliance & Safety | |
6.1 | Drop Resistance: | Withstands 1-meter free fall |
6.2 | Certifications: | CE, RoHS, FCC |
